Item
Contents
Unit
Display format
16 Characters x 2 Lines
--
LCD duty
1/16
LCD bias
1/5
LCD voltage
4.5
V
Controller/Driver
ST7066U & PIC16F690
Module size (W x H)
80.0 x 36.0
mm
Viewing area (W x H)
64.5 x 16.4
Character size (W x H)
3.00 x 5.23
Dot size (W x H)
0.56 x 0.61
Dot pitch (W x H)
0.61 x 0.66
