PLC0801CW

Model:PLC0801CW
Download

Item

Contents

Unit

Display format

8 Characters x 1 Lines

--

LCD duty

1/16

--

LCD bias

1/5

--

LCD voltage

4.5

V

Controller/Driver

ST7066U or Equivalent

--

Module size (W x H)

53.0 x 24.2

mm

Viewing area (W x H)

35.0 x 13.2

mm

Character size (W x H)

3.4 x 7.1

mm

Dot size (W x H)

0.60 x 0.80

mm

Dot pitch (W x H)

0.70 x 0.90

mm



The display format features 8 characters in one row, providing a concise display for crucial data, making it ideal for applications requiring limited space.

With a 1/16 LCD working cycle and a 1/5 LCD field bias, this display ensures smooth and reliable performance, delivering consistent visuals without flickering.

Operating at 4.5 V, the LCD work voltage is optimized for efficient power consumption, providing extended usage time and saving energy.

Equipped with the ST7066U controller or an equivalent product, this display guarantees precise and reliable control, ensuring smooth and accurate data presentation.

The module size of 53.0x24.2 millimeters ensures easy integration into your device, making it perfect for compact applications.

The visible area measures 35.0x13.2 millimeters, providing ample space for essential information to be displayed clearly and legibly.

Each character is designed with a size of 3.4x7.1 millimeters, ensuring clear and easily readable characters.

With a pixel size of 0.60x0.80 millimeters and pixel pitch of 0.70x0.90 millimeters, the display delivers sharp and well-defined details, enhancing the overall visual quality.
