2.7 inch oled display
|
Item |
Contents |
Unit |
|
Diagonal |
2.70" |
-- |
|
Display format |
128 × 64 |
dots |
|
Controller/Driver |
SSD1327ZC |
-- |
|
Module size (W x H x T) |
73.00 × 40.24 × 2.00 |
mm |
|
Active area (W x H) |
61.41 × 30.69 |
mm |
|
Viewing area (W x H) |
63.41 × 32.69 |
mm |
|
Pixel size (W x H) |
0.45 × 0.45 |
mm |
|
Pixel pitch (W x H) |
0.48 × 0.48 |
mm |
|
Display colors |
Blue / Green / Red / White / Yellow / Orange |
colors |
|
Interface |
Parallel / SPI / IIC |
-- |
