122x32 graphic lcd pqg1206pw
|
Item |
Contents |
Unit |
|
Display format |
128 × 64 |
dots |
|
LCD duty |
1/65 |
-- |
|
LCD bias |
1/9 |
-- |
|
LCD voltage |
9.4 |
V |
|
Controller/Driver |
UC1701X |
-- |
|
Module size (W x H) |
39.0 × 30.0 |
mm |
|
Viewing area (W x H) |
34.6 × 22.4 |
mm |
|
Dot size (W x H) |
0.217 × 0.264 |
mm |
|
Dot pitch (W x H) |
0.242 × 0.289 |
mm |
